Fiber Optics Distribution Box GP31-2P16F-1
Overview
LongXing GP31-2P16F-1 distribution box is used as a termination point for the feeder cable to connect with drop cable in FTTx communication network system. The fiber splicing, splitting, distribution can be done in this box, and meanwhile it provides solid protection and management for the FTTx network building.
Features
l Total enclosed structure.
l Material: PC+ABS
l Wet-proof, water-proof, dust-proof, anti-aging
l Protection level up to IP65.
l Clamping for feeder cable and drop cable, fiber splicing, fixation, storage, distribution all in one.
l Suitable for SC and LC duplex adapter and pigtail
l Easy to operate
l Suitable for both outdoor and indoor use
l Protects and manages cable effectively
l Secured with anti-theft locking mechanism
l Standard size, light weight
| Dimensions and Capability | |
| Dimensions (H*W*D) | 317mm*237mm*101mm |
| Adapter Capacity | SC 16 PCs |
| Number of Cable Entrance/Exit | 3 / 16 |
| Weight | 1 KG |
| Optional Accessories | Adapters, Pigtails, Heat Shrink Tubes, Splitters, Splice Tray |
| Insertion loss | ≤0.2dB |
| UPC return loss | ≥50dB |
| APC return loss | ≥60dB |
| Life of insertion and extraction | ≥1000 times |
| Insulation | The ground device is insulated with the Distribution box, IR ≥1000mΩ/500V(direct current) |
| Withstand Voltage | Between the grounding device and the box body, the withstand voltage is over 3000V/Min, no breakdown and flashover. U≥3000V(Direct current) |
| Operation Conditions | |
| Temperature | -40℃ -- +85℃ |
| Humidity | ≤ 85% (+30℃) |
| Air Pressure | 70kPa – 106kPa |
| Shipping Information | |
| Package Contents | Distribution box, 1 unit; Keys for lock, 1keys Wall mount installation accessories, 1 set |
| Package Dimensions(W*H*D) | 380mm*300mm*160mm |
| Material | Carton box |
| Weight | 1.5 KG |
| Lead Time | 10-15 working days normally |
