Modular MTP/MPO-LC Patch Panel ODU-L30
Overview
The LongXing High Density 144-core MPO Patch Panel is purpose-built for high-density fiber deployments in data centers and telecommunication networks. Factory pre-terminated and tested, it reduces on-site installation time and enhances system reliability. The patch panel supports quick connections to LC adapters via LongXing’s MPO trunk cables (sold separately) and fits standard 19" or 23" racks or cabinets. It accommodates up to 144 LC fiber terminations, ensuring efficient fiber management in compact spaces.
Features
- UP to 144 Fiber LC Ports in 1U
- Flexibility to Mix Adapter Plates with Cassettes in Patch Panel
- Available in SM, OM1, OM2, OM3 and OM4 fiber grades
- Flat Front Panel for Optimal Cable Routing
- Removable Top for Easier Fiber Cable Management
- Compliant IEC-61754-7, EIA/TIA-604-5 & RoHS
