Horizontal Cable Manager
Overview
Horizontal cable managers ensure optimal cable radius to prevent deterioration or breakage. Flexible fingers maximize thecare and protection of the equipment and cables, keeping the structured cabling system unhurt and totally functional. Removable cover makes it easy to add or remove bundled cables quickly.
High capacity horizontal cable managers provide an efficient way to manage high performance copper, fiber and etc. on any 19" rack.
Features
l Integral bend radius control - Maintains bend radius as cables transition to and from horizontal and vertical path ways.
l Flexible finger dusts - Provides for easy installation and organizes cables simplifying moves, add-ons, and changes.
l Cable pass through holes - Provides ease of installation and cable maintenance.
l Available in 2U version
Add To Quote List
Add To Compare
Inquiry Now
l Flexible finger dusts - Provides for easy installation and organizes cables simplifying moves, add-ons, and changes.
l Cable pass through holes - Provides ease of installation and cable maintenance.
l Available in 2U version
| Product Specifications | |||
| Part Number | LX-CMH-1U | LX-CMH-2U | |
| No. of Rack Spaces | 1U | 2U | |
| Style | Finger Duct with Cover | ||
| Material | ABS | Cold rolled steel | |
| Color | Black | ||
| Orientation | Horizontal | ||
| Pass-through Holes | 2 | ||
| Detachable cover | Yes | ||
| Application | Fiber, Copper and etc. | ||
| Dimensions (W x H x D) | 483 x 44.5 x 65mm | 483 x 88 x 70mm | |
| Shipping Information | |
| Package Contents | Horizontal cable manager, 1 unit |
| Package Dimensions(W*H*D) | Individual internal box for each piece 540 x 450 x 510 mm (50 Pcs per outer carton - 1U) 500 x 450 x 500 mm (25 Pcs per outer carton - 2U) |
| Material | Carton box |
| Weight | It depends on the dimensions of the product |
| Lead Time | 15 working days normally |
