4G SFP
Overview
Fibre Channel, or FC, is a gigabit-speed network technology primarily used for storage networking. Fibre Channel is standardized in the T11 Technical Committee of the International Committee for Information Technology Standards (INCITS), an American National Standards Institute (ANSI)–accredited standards committee. It started use primarily in the supercomputer field, but has become the standard connection type for storage area networks (SAN) in enterprise storage. Despite its name, Fibre Channel signaling can run on both twisted pair copper wire and fiber-optic cables.
Line-Rate :1GFC 1.0625 ; 2GFC 2.125; 4GFC 4.25
Features
Add To Quote List Add To Compare Inquiry Now| Specifications | |||||||||
| Package | P/N | Data Rate | Wavelength | OSA Type | Distance | Connector | Case Temp. | DDM | Application |
| SFP | ZD5AM16-DxL | Up to 4.25Gbps | 850nm | VCSEL/PIN | 150m | LC | Com./Ind. | D | FC |
| SFP | ZD5B056-DxL | Up to 4.25Gbps | 1310nm | FP/PIN | 5km | LC | Com./Ind. | D | FC |
| SFP | ZD5D106-DxL | Up to 4.25Gbps | 1310nm | DFB/PIN | 10km | LC | Com./Ind. | D | FC |
| SFP | ZD5D206-DxL | Up to 4.25Gbps | 1310nm | DFB/PIN | 20km | LC | Com./Ind. | D | FC |
| SFP | ZD5E406-DxL | Up to 4.25Gbps | 1550nm | DFB/PIN | 40km | LC | Com./Ind. | D | FC |
| SFP | ZD5G806-DxL | Up to 4.25Gbps | 1550nm | DFB/APD | 80km | LC | Com./Ind. | D | FC |
| Shipping Information | |
| Package Contents | Distribution box, 1 unit; Keys for lock, 2 keys |
| Package Dimensions(W*H*D) | 190mm*50mm*120mm |
| Material | Carton box |
| Weight | 0.82 KG |
| Lead Time | 10-15 working days normally |
