CWDM SFP
Overview
LongXing offers full range of fiber optic transceiver such as SFP, GBIC, SFP+, XFP, X2 & XENPAK, 40G QSFP+ & CFP, CWDM DWDM, 3G-SDI video SFP transceiver with Lifetime Warranty, ROHS Compliant, 100% Test Assured
Features
l Hot-Pluggable SFP Footprint LC Optical Transceiver
l Small Form-Factor Pluggable (SFP) MSA compatible
l Compliant with IEEE 802.3z Gigabit Ethernet 1000BASE-ZX
l Compliant with Fibre Channel 1X SM-LC-L FC-PI
l 18 Wavelength (λ): 1270 nm to 1610 nm CWDM DFB LD Transmitter
l Up to 41dB dB Power Budget
l AC/AC Coupling according to MSA
l Single +3.3 V Power Supply
l RoHS Compliant
l 0 to 70C, -10 to 85C or -40 to 85C Case Operation Temperature Ranges
l Class 1 Laser International Safety Standard IEC 60825 Compliant
l Class 1 Laser International Safety Standard IEC 60825 Complian
l Class 1 Laser International Safety Standard IEC 60825 Complian
| Specifications | ||||||||||
| Package | P/N | Data Rate | Wavelength | OSA Type | Power Budget | Connector | Case Temp. | DDM | Application |
|
| CWDM SFP | ZD5J291-DxL | 100M~155Mbps | CWDM | DFB/PIN | 29DB | LC | Com./Ind. | D | FE, SDH, SONET, FTTx | |
| CWDM SFP | ZD5J341-DxL | 100M~155Mbps | CWDM | DFB/PIN | 34DB | LC | Com./Ind. | D | FE, SDH, SONET, FTTx | |
| CWDM SFP | ZD5J371-DxL | 100M~155Mbps | CWDM | DFB/PIN | 37DB | LC | Com./Ind. | D | FE, SDH, SONET, FTTx | |
| CWDM SFP | ZD5K451-DxL | 100M~155Mbps | CWDM | DFB/APD | 45DB | LC | Com./Ind. | D | FE, SDH, SONET, FTTx | |
| CWDM SFP | ZD5J232-DxL | 100M~622Mbps | CWDM | DFB/PIN | 23dB | LC | Com./Ind. | D | SDH, SONET, FTTx | |
| CWDM SFP | ZD5J282-DxL | 100M~622Mbps | CWDM | DFB/PIN | 28dB | LC | Com./Ind. | D | SDH, SONET, FTTx | |
| CWDM SFP | ZD5K342-DxL | 100M~622Mbps | CWDM | DFB/APD | 34dB | LC | Com. | D | SDH, SONET, FTTx | |
| CWDM SFP | ZD5K392-DxL | 100M~622Mbps | CWDM | DFB/APD | 39dB | LC | Com. | D | SDH, SONET, FTTx | |
| CWDM SFP | ZD5J193-DxL | Up to 1.25Gbps | CWDM | DFB/PIN | 19dB | LC | Com./Ind. | D | GBE, FC, FTTx | |
| CWDM SFP | ZD5J243-DxL | Up to 1.25Gbps | CWDM | DFB/PIN | 24dB | LC | Com./Ind. | D | GBE, FC, FTTx | |
| CWDM SFP | ZD5J283-DxL | Up to 1.25Gbps | CWDM | DFB/PIN | 28dB | LC | Com./Ind. | D | GBE, FC, FTTx | |
| CWDM SFP | ZD5K343-DxL | Up to 1.25Gbps | CWDM | DFB/APD | 34dB | LC | Com./Ind. | D | GBE, FC, FTTx | |
| CWDM SFP | ZD5K413-DxL | Up to 1.25Gbps | CWDM | DFB/APD | 41dB | LC | Com./Ind. | D | GBE, FC, FTTx | |
| CWDM SFP | ZD5J154-DxL | Up to 2.5Gbps | CWDM | DFB/PIN | 15dB | LC | Com./Ind. | D | GBE, FC, SDH, SONET | |
| CWDM SFP | ZD5J174-DxL | Up to 2.5Gbps | CWDM | DFB/PIN | 17dB | LC | Com./Ind. | D | GBE, FC, SDH, SONET | |
| CWDM SFP | ZD5K294-DxL | Up to 2.5Gbps | CWDM | DFB/APD | 29dB | LC | Com./Ind. | D | GBE, FC, SDH, SONET | |
| CWDM SFP | ZD5K344-DxL | Up to 2.5Gbps | CWDM | DFB/APD | 34dB | LC | Com./Ind. | D | GBE, FC, SDH, SONET | |
| CWDM SFP | ZD5J154-DxL | Up to 2.67Gbps | CWDM | DFB/PIN | 15dB | LC | Com./Ind. | D | GBE, FC, SDH, SONET, MultiRate | |
| CWDM SFP | ZD5J174-DxL | Up to 2.67Gbps | CWDM | DFB/PIN | 17dB | LC | Com./Ind. | D | GBE, FC, SDH, SONET, MultiRate | |
| CWDM SFP | ZD5K294-DxL | Up to 2.67Gbps | CWDM | DFB/APD | 29dB | LC | Com./Ind. | D | GBE, FC, SDH, SONET, MultiRate | |
| CWDM SFP | ZD5K344-DxL | Up to 2.67Gbps | CWDM | DFB/APD | 34dB | LC | Com. | D | GBE, FC, SDH, SONET, MultiRate | |
| CWDM SFP | ZD5J136-DxL | Up to 4.25Gbps | CWDM | DFB/PIN | 13dB | LC | Com./Ind. | D | FC | |
| CWDM SFP | ZD5J186-DxL | Up to 4.25Gbps | CWDM | DFB/PIN | 18dB | LC | Com./Ind. | D | FC | |
| CWDM SFP | ZD5K266-DxL | Up to 4.25Gbps | CWDM | DFB/APD | 26dB | LC | Com./Ind. | D | FC | |
| Shipping Information | |
| Package Contents | Distribution box, 1 unit; Keys for lock, 2 keys |
| Package Dimensions(W*H*D) | 190mm*50mm*120mm |
| Material | Carton box |
| Weight | 0.82 KG |
| Lead Time | 10-15 working days normally |
