DWDM SFP

Overview

LongXing's Dense Wavelength Division Multiplexing (DWDM) SFP transceivers provide the high speeds and physical compactness that today's networks require while delivering the deployment flexibility and inventory control that network administrators demand. Our DWDM SFPs are available in all 100 GHz or 50Ghz C-band wavelengths on the DWDM ITU Grid. They are designed to MSA standards to ensure broad network equipment compatibility. As multirate interfaces they support any protocol from 100 Mbps to 4.25 Gbps. The transceivers are small form factor pluggable modules for bi-directional serial optical data communications such as 4x/2x/1x Fibre Channel, SDH/SONET, Ethernet applications. The modules are hot pluggable and digital diagnostic functions area available via an I2C serial bus specified in the SFP MSA SFF-8472. The modules meet the requirements of the IEEE802.3 Gigabit Ethernet standard and ANSI Fibre Channel specifications, and are suitable for interconnections in Gigabit Ethernet and Fibre Channel environments.

Features

Add To Quote List Add To Compare
Specifications
Package P/N Data Rate Wavelength OSA Type Power Budget Connector Case Temp. DDM Application
DWDM SFP ZD5J291-DxLxx 100M~155Mbps 100GHz DWDM DFB/PIN 29DB LC Com./Ind. D FE, SDH, SONET, FTTx
DWDM SFP ZD5J341-DxLxx 100M~155Mbps 100GHz DWDM DFB/PIN 34DB LC Com./Ind. D FE, SDH, SONET, FTTx
DWDM SFP ZD5J371-DxLxx 100M~155Mbps 100GHz DWDM DFB/PIN 37DB LC Com./Ind. D FE,SDH, SONET, FTTx
DWDM SFP ZD5K451-DxLxx 100M~155Mbps 100GHz DWDM DFB/APD 45DB LC Com./Ind. D FE, SDH, SONET, FTTx
DWDM SFP ZD5J291-DxLxx 100M~155Mbps 50GHz DWDM DFB/PIN 29DB LC Com./Ind. D FE, SDH, SONET, FTTx
DWDM SFP ZD5J341-DxLxx 100M~155Mbps 50GHz DWDM DFB/PIN 34DB LC Com./Ind. D FE, SDH, SONET, FTTx
DWDM SFP ZD5J371-DxLxx 100M~155Mbps 50GHz DWDM DFB/PIN 37DB LC Com./Ind. D FE, SDH, SONET, FTTx
DWDM SFP ZD5K451-DxLxx 100M~155Mbps 50GHz DWDM DFB/APD 45DB LC Com./Ind. D FE, SDH, SONET, FTTx
DWDM SFP ZD5J232-DxLxx 100M~622Mbps 100GHz DWDM DFB/PIN 23dB LC Com./Ind. D SDH, SONET, FTTx
DWDM SFP ZD5J282-DxLxx 100M~622Mbps 100GHz DWDM DFB/PIN 28dB LC Com./Ind. D SDH, SONET, FTTx
DWDM SFP ZD5K342-DCLxx 100M~622Mbps 100GHz DWDM DFB/APD 34dB LC Com. D SDH, SONET, FTTx
DWDM SFP ZD5K392-DCLxx 100M~622Mbps 100GHz DWDM DFB/APD 39dB LC Com. D SDH, SONET, FTTx
DWDM SFP ZD5J232-DxLxx 100M~622Mbps 50GHz DWDM DFB/PIN 23dB LC Com./Ind. D SDH, SONET, FTTx
DWDM SFP ZD5J282-DxLxx 100M~622Mbps 50GHz DWDM DFB/PIN 28dB LC Com./Ind. D SDH, SONET, FTTx
DWDM SFP ZD5K342-DCLxx 100M~622Mbps 50GHz DWDM DFB/APD 34dB LC Com. D SDH, SONET, FTTx
DWDM SFP ZD5K392-DCLxx 100M~622Mbps 50GHz DWDM DFB/APD 39dB LC Com. D SDH, SONET, FTTx
DWDM SFP ZD5J193-DxLxx up to 1.25Gbps 100GHz DWDM DFB/PIN 19dB LC Com./Ind. D GBE, FC, FTTx
DWDM SFP ZD5J243-DxLxx up to 1.25Gbps 100GHz DWDM DFB/PIN 24dB LC Com./Ind. D GBE, FC, FTTx
DWDM SFP ZD5J283-DxLxx up to 1.25Gbps 100GHz DWDM DFB/PIN 28dB LC Com./Ind. D GBE, FC, FTTx
DWDM SFP ZD5K323-DxLxx up to 1.25Gbps 100GHz DWDM DFB/APD 32dB LC Com./Ind. D GBE, FC, FTTx
DWDM SFP ZD5K373-DxLxx up to 1.25Gbps 100GHz DWDM DFB/APD 37dB LC Com./Ind. D GBE, FC, FTTx
DWDM SFP ZD5J193-DxLxx up to 1.25Gbps 50GHz DWDM DFB/PIN 19dB LC Com./Ind. D GBE, FC, FTTx
DWDM SFP ZD5J243-DxLxx up to 1.25Gbps 50GHz DWDM DFB/PIN 24dB LC Com./Ind. D GBE, FC, FTTx
DWDM SFP ZD5J283-DxLxx up to 1.25Gbps 50GHz DWDM DFB/PIN 28dB LC Com./Ind. D GBE, FC, FTTx
DWDM SFP ZD5K323-DxLxx up to 1.25Gbps 50GHz DWDM DFB/APD 32dB LC Com./Ind. D GBE, FC, FTTx
DWDM SFP ZD5K373-DxLxx up to 1.25Gbps 50GHz DWDM DFB/APD 37dB LC Com./Ind. D GBE, FC, FTTx
DWDM SFP ZD5J154-DxLxx up to 2.5Gbps 100GHz DWDM DFB/PIN 15dB LC Com./Ind. D GBE, FC, SDH, SONET
DWDM SFP ZD5J174-DxLxx up to 2.5Gbps 100GHz DWDM DFB/PIN 17dB LC Com./Ind. D GBE, FC, SDH, SONET
DWDM SFP ZD5K294-DxLxx up to 2.5Gbps 100GHz DWDM DFB/APD 29dB LC Com./Ind. D GBE, FC, SDH, SONET
DWDM SFP ZD5K344-DCLxx up to 2.5Gbps 100GHz DWDM DFB/APD 34dB LC Com. D GBE, FC, SDH, SONET
DWDM SFP ZD5J154-DxLxx up to 2.5Gbps 50GHz DWDM DFB/PIN 15dB LC Com./Ind. D GBE, FC, SDH, SONET
DWDM SFP ZD5J174-DxLxx up to 2.5Gbps 50GHz DWDM DFB/PIN 17dB LC Com./Ind. D GBE, FC, SDH, SONET
DWDM SFP ZD5K294-DxLxx up to 2.5Gbps 50GHz DWDM DFB/APD 29dB LC Com./Ind. D GBE, FC, SDH, SONET
DWDM SFP ZD5K344-DCLxx up to 2.5Gbps 50GHz DWDM DFB/APD 34dB LC Com. D GBE, FC, SDH, SONET
DWDM SFP ZD5J154-DxLxx up to 2.67Gbps 100GHz DWDM DFB/PIN 15dB LC Com./Ind. D GBE, FC, SDH, SONET
DWDM SFP ZD5J174-DxLxx up to 2.67Gbps 100GHz DWDM DFB/PIN 17dB LC Com./Ind. D GBE, FC, SDH, SONET
DWDM SFP ZD5K294-DxLxx up to 2.67Gbps 100GHz DWDM DFB/APD 29dB LC Com./Ind. D GBE, FC, SDH, SONET
DWDM SFP ZD5K324-DxLxx up to 2.67Gbps 100GHz DWDM DFB/APD 32dB LC Com. D GBE, FC, SDH, SONET
DWDM SFP ZD5J154-DxLxx up to 2.67Gbps 50GHz DWDM DFB/PIN 15dB LC Com./Ind. D GBE, FC, SDH, SONET
DWDM SFP ZD5J174-DxLxx up to 2.67Gbps 50GHz DWDM DFB/PIN 17dB LC Com./Ind. D GBE, FC, SDH, SONET
DWDM SFP ZD5K294-DxLxx up to 2.67Gbps 50GHz DWDM DFB/APD 29dB LC Com./Ind. D GBE, FC, SDH, SONET
DWDM SFP ZD5K324-DCLxx up to 2.67Gbps 50GHz DWDM DFB/APD 32dB LC Com. D GBE, FC, SDH, SONET
DWDM SFP ZD5J136-DxLxx up to 4.25Gbps 100GHz DWDM DFB/PIN 13dB LC Com./Ind. D FC
DWDM SFP ZD5J186-DxLxx up to 4.25Gbps 100GHz DWDM DFB/PIN 18dB LC Com./Ind. D FC
DWDM SFP ZD5K266-DxLxx up to 4.25Gbps 100GHz DWDM DFB/APD 26dB LC Com./Ind. D FC
DWDM SFP ZD5J136-DxLxx up to 4.25Gbps 50GHz DWDM DFB/PIN 13dB LC Com./Ind. D FC
DWDM SFP ZD5J186-DxLxx up to 4.25Gbps 50GHz DWDM DFB/PIN 18dB LC Com./Ind. D FC
DWDM SFP ZD5K266-DxLxx up to 4.25Gbps 50GHz DWDM DFB/APD 26dB LC Com./Ind. D FC




Shipping Information
Package Contents Distribution box, 1 unit; Keys for lock, 2 keys
Package Dimensions(W*H*D) 190mm*50mm*120mm
Material Carton box
Weight 0.82 KG
Lead Time 10-15 working days normally
