SFP ETHERNET
Overview
The IEEE 802.3z standard includes 1000BASE-SX for transmission over multi-mode fiber, 1000BASE-LX for transmission over single-mode fiber, 100BASE-FX is a version of Fast Ethernet over optical fiber. It uses a 1300 nm near-infrared (NIR) light wavelength transmitted via two strands of optical fiber, one for receive and the other for transmit, 100BASE-SX is a version of Fast Ethernet over optical fiber. It uses two strands of multi-mode optical fiber for receive and transmit. ZKTel produces complete range for FE and GE optical fiber transceivers.
Features
Add To Quote List Add To Compare Inquiry Now| Specifications | |||||||||
| Package | P/N | Data Rate | Wavelength | OSA Type | Distance | Connector | Case Temp. | DDM | Application |
| SFP | ZD5B021-DxL | 100M~155Mbps | 1310nm | FP/PIN | 2km | LC | Com./Ind. | D | FE, SDH, SONET, FTTx |
| SFP | ZD5B151-DxL | 100M~155Mbps | 1310nm | FP/PIN | 15km | LC | Com./Ind. | D | FE, SDH, SONET, FTTx |
| SFP | ZD5B401-DxL | 100M~155Mbps | 1310nm | FP/PIN | 40km | LC | Com./Ind. | D | FE, SDH, SONET, FTTx |
| SFP | ZD5D501-DxL | 100M~155Mbps | 1310nm | DFB/PIN | 80km | LC | Com./Ind. | D | FE, SDH, SONET, FTTx |
| SFP | ZD5C151-DxL | 100M~155Mbps | 1550nm | FP/PIN | 15km | LC | Com./Ind. | D | FE, SDH, SONET, FTTx |
| SFP | ZD5E801-DxL | 100M~155Mbps | 1550nm | DFB/PIN | 80km | LC | Com./Ind. | D | FE, SDH, SONET, FTTx |
| SFP | ZD5EA01-DxL | 100M~155Mbps | 1550nm | DFB/PIN | 100km | LC | Com./Ind. | D | FE, SDH, SONET, FTTx |
| SFP | ZD5EA21-DxL | 100M~155Mbps | 1550nm | DFB/PIN | 120km | LC | Com./Ind. | D | FE, SDH, SONET, FTTx |
| SFP | ZD5EA61-DxL | 100M~155Mbps | 1550nm | DFB/PIN | 160km | LC | Com./Ind. | D | FE, SDH, SONET, FTTx |
| SFP | ZD5EB01-DxL | 100M~155Mbps | 1550nm | DFB/PIN | 200km | LC | Com./Ind. | D | FE, SDH, SONET, FTTx |
| SFP | ZD5AM53-DxL | Up to 1.0625 Gbps |
850nm | VCSEL/PIN | 0.550km | LC | Com./Ind. | D | Ethernet, FC |
| SFP | ZD5BM53-DxL | Up to 1.25Gbps | 1310nm | FP/PIN | 0.550km | LC | Com./Ind. | D | GBE, FC, FTTx |
| SFP | ZD5B103-DxL | Up to 1.25Gbps | 1310nm | FP/PIN | 10km | LC | Com./Ind. | D | GBE, FC, FTTx |
| SFP | ZD5B153-DxL | Up to 1.25Gbps | 1310nm | FP/PIN | 15km | LC | Com./Ind. | D | GBE, FC, FTTx |
| SFP | ZD5B203-DxL | Up to 1.25Gbps | 1310nm | FP/PIN | 20km | LC | Com./Ind. | D | GBE, FC, FTTx |
| SFP | ZD5D403-DxL | Up to 1.25Gbps | 1310nm | DFB/PIN | 40km | LC | Com./Ind. | D | GBE, FC, FTTx |
| SFP | ZD5E403-DxL | Up to 1.25Gbps | 1550nm | DFB/PIN | 40km | LC | Com./Ind. | D | GBE, FC, FTTx |
| SFP | ZD5E803-DxL | Up to 1.25Gbps | 1550nm | DFB/PIN | 80km | LC | Com./Ind. | D | GBE, FC, FTTx |
| SFP | ZD5GA03-DxL | Up to 1.25Gbps | 1550nm | DFB/PIN | 100km | LC | Com./Ind. | D | GBE, FC, FTTx |
| SFP | ZD5GA23-DxL | Up to 1.25Gbps | 1550nm | DFB/PIN | 120km | LC | Com./Ind. | D | GBE, FC, FTTx |
| SFP | ZD5GA63-DxL | Up to 1.25Gbps | 1550nm | DFB/PIN | 160km | LC | Com./Ind. | D | GBE, FC, FTTx |
| SFP | ZD5AM54-DxL | Up to 2.125Gbps | 850nm | VCSEL/PIN | 550m | LC | Com./Ind. | - | GBE, FC, SDH, SONET |
| Shipping Information | |
| Package Contents | Distribution box, 1 unit; Keys for lock, 2 keys |
| Package Dimensions(W*H*D) | 190mm*50mm*120mm |
| Material | Carton box |
| Weight | 0.82 KG |
| Lead Time | 10-15 working days normally |
